DEHNcare APS with headgear
:quality(98)/dehn.us/store/f/51554284/HDVORSCHAU/785870a0001.jpg)
:quality(98)/dehn.us/store/f/51554284/HDVORSCHAU/785870a0001.jpg)
- Face shield with headgear for protection against the mechanical and thermal hazards of an electric arc during live working or when in close proximity to live parts.
- Arcing class APC 1
- Certified according to PPE regulation (EU) 2016/425
Part No. 785870 APS ARC E1 SK7
GTIN 4013364497504, Customs tariff No. (EU): 39269060, Gross weight: 446.03 g, PU: 1.00 pc(s)
Images
:quality(98)/dehn.us/store/f/51554289/HDVORSCHAU/785870.jpg)
:quality(98)/dehn.us/store/f/51554289/HDVORSCHAU/785870.jpg)
Certificates
Technical data
| Nominal voltage up to (UN ) | 1000 V |
| Colour | Transparent |
| Material | Polycarbonate |
| Wall thickness | approx. 2 mm |
| Arc fault protection class (box test 4 kA / 0.5 s – single-pole) | APC 1 |
| Arc energy (Warc or WLBP ) | 168 kJ |
| Standard | GS-ET 29, EN 166 |
